hydrophilic aluminium foil is mainly used for air conditioner cooling effect, at present the thickness is only 0.09 to 0.15 mm, the air conditioner aluminum foil adapts to the home appliance charactristic of small, high efficiency and long life better. Now according to the performance of air conditioning, all kinds of air condition aluminum foil have been developed with variety of effects, such as the hydrophilic air condition aluminum foil, hydrophobic heat transfer surface, anti-corrosion air condition aluminum foil, mouldproof air condition aluminum foil and self-lubrication air condition aluminum foil, etc.
Specification
| Alloy: | 1100, 8011 |
| Temper: | O, H18, H22, H24, H26 |
| Thickness: | 0.08~0.20mm |
| Width: | 100~1240mm |
| Coil ID: | 75, 150, 505 |
Chemical Compositions
| Alloy | Fe | Si | Cu | Mn | Mg | Cr | Zn | Ni | Ti | Other | Al |
|
| Each | Total |
|
|
|
|
|
|
|
|
|
|
|
| 1100 | 0.95 | 0.05~0.20 | 0.05 | - | - | 0.1 | - | - | 0.05 | 0.15 | 99 |
|
| 8011 | 0.6~1.0 | 0.50~0.9 | 0.1 | 0.2 | 0.05 | 0.05 | 0.1 | - | 0.08 | 0.05 | 0.15 | Remains |
Mechanical Properies
Aolly,temper and mechanical performance under room temperature
| Alloy | Temper | Mechanical performance under room temperature |
|
|
| Tensile(∮b, Mpa) | Elongation(e%) | Erichson(IE,mm) |
|
|
| 1100, 8011 | O | 80-110 | >20 | >6.0 |
| H22 | 100-135 | >16 | >5.5 |
|
| H24 | 115-145 | >12 | >5.0 |
|
| H26 | 125-160 | >8 | >4.0 |
|
| H18 | >160 | >1 | -- |
|
| Re:if customers have special requirements,pls indicate them in purchase order |
|
|
|
|
Usually supplied specification
| Thickness and tolerance | Width and tolerance (mm) | Core ID (mm) | Max OD for Finish products (mm) | Core material |
| 0.08~0.02 (+/-0.005) | 100~1100(+/-0.5) | ∮75, ∮150, | ∮</=1400 | Paper,aluminium,steel |
Feature:
Good high temperature and climate resisitance;
Strong and smooth adhesion;
Application:
Aluminum foil roll is widely used in construction,decoration,hardware,electric appliances,machinery and other
industrial and civil purposes,such as electronic capacitor,composite cooker,rice cooker,refrigerator,computer casting,telecommunication,equipment,lamp shade,air conditioner,cosmetics cover and so on.
