8011 Aluminum Coil
8011 Aluminium coil is widely used for household air conditioners,refrigerators,HVAC industries.We can supply the bare foil,hydrophilic foil with colors such as blue,gold,white etc.
Hydrophilic aluminum foil is a necessary material for all kinds of air conditioners, refrigerators, freezers and other refrigeration equipment.The mechanical properties and hydrophilic properties can meet the punching requirements of various types of punch machines for the production of heat exchange fins.
Specification:
Product | Alloy | Temper | Thickness(mm) | Width(mm) | I.D.(mm) | O.D.(mm) |
Finstock | 8011 | HO/H22/H24/H26/H18 | 0.08-0.2 | 60-1440 | 75/150/200/300/400 | 400-1500mm |
Mechanical properties(For reference only)
Temper | Tensile strength(MPa) | Elongation(%) | Erichsen(mm) |
HO | 80-110 | 20 | 6.0 |
H22 | 100-135 | 16 | 5.5 |
H24 | 115-145 | 12 | 5.0 |
H26 | 125-160 | 8 | 4.0 |
H18 | 160 | 1 | - |
