5083 Aluminum sheet
5083 aluminum sheet belongs to Al-Mg-Si aluminium alloys. Its main contents are Magnesium and Silicon except Aluminium. Over 4.0% of Magnesium enables 5083 aluminium plate to have excellent resistance to correction
Contact Us
WhatsAPP
QR code
Detail
5083 aluminum sheet belongs to Al-Mg-Si aluminium alloys. Its main contents are Magnesium and Silicon except Aluminium. Over 4.0% of Magnesium enables 5083 aluminium plate to have excellent resistance to correction, and easily to welded. By adding cooper, 5083 aluminium plate has 28% Electrical conductivity. 5083 aluminium plate also has good forming characteristic for either hot or cold working. But hardening is accomplished by means of cold working only. Besides, 5083 aluminium plate does have good strength but non-heat treatable.
5083 Aluminum sheet Chemical Composition
| ELEMRNTS | Mg | Si | Iron | Ti | Cu | Mn | Cr | Zn | Others Each | Others Total | B |
| CONTENT (WT%) | 4.0-4.9 | ≤0.4 | 0.4 | ≤0.15 | ≤0.1 | 0.4-1.0 | 0.05-0.25 | 0.25 | 0.05 | 0.15 | A |
5083 Aluminum sheet Mechanical Properties
| Typical Temper | Tensile Strength | Yield Strength | Elongation | Thickness | Width | Length |
| (KSI) | (KSI) | (%) | (mm) | (mm) | (mm) | |
| O(annealed) | 42 | 21 | 14 | 0.5-600 | 500-3100 | Max1600 |
| H122 | 43 | 23 | 10 | |||
| H116 | 46 | 33 | 10 | |||
| H321 | 48 | 33 | 10 |
