1100 Aluminum Sheet
1100 aluminum sheet is the most commercially pure alloy of all the aluminium grades.it is a typical industrial pure aluminium (99.00% of aluminum),
Contact Us
WhatsAPP
QR code
Detail
1100 aluminum sheet is the most commercially pure alloy of all the aluminium grades.it is a typical industrial pure aluminium (99.00% of aluminum), and cannot be heat treated.It has some features such as high anti-corrosion, great electrical conductivity and thermal conductivity, low density, plasticity is pretty good that can produce some aluminium profiles by pressure processing,aluminium alloy 1100 is a low strength aluminium alloy with excellent corrosion resistance. This grade is best used for welding, brazing and soldering but has poor machinability. aluminium alloy 1100 aluminium has great finishing capabilities so it is a great choice for decorative purposes.
| Alloy | Temper | Thickness(mm) | Width(mm) | Length(mm) | Typical products |
| 1100 aluminium sheet | O,H12,H14,H16 H18,H19,H22,H24 H26,H28,H32,H34 H36,H38 | 0.2-4.5 | 100-2600 | 500-16000 | Kitchen utensils, building materials, heat exchangers, etc. |
1100 Aluminum sheet Properties
| Content | 0.95 | 0.05-0.2 | 0.05 | - | - | 0.1 | - | 0.15 | Remain | |
| Alloy Temper | Specified | Tensile strength | Yield strength | Elongation | ||||||
| Thickness(in.) | (ksi) | (ksi) | (%) | |||||||
| 1100-O (annealed) | 0.006-0.019 | 11.0-15.5 | Min3.5 | Min15 | ||||||
| 0.020-0.031 | Min20 | |||||||||
| 0.032-0.050 | Min25 | |||||||||
| 0.051-0.249 | Min30 | |||||||||
| 0.250-3.000 | Min28 | |||||||||
| 1100-H12/1100-H22 | 0.017-0.019 | 14.0-19.0 | Min11.0 | Min3 | ||||||
| 0.020-0.031 | Min4 | |||||||||
| 0.032-0.050 | Min6 | |||||||||
| 0.051-0.113 | Min8 | |||||||||
| 0.114-0.499 | Min9 | |||||||||
| 0.500-2.000 | Min12 | |||||||||
| 1100-H14/1100-H24 | 0.009-0.012 | 16.0-21.0 | Min14.0 | Min1 | ||||||
| 0.013-0.019 | Min2 | |||||||||
| 0.020-0.031 | Min3 | |||||||||
| 0.032-0.050 | Min4 | |||||||||
| 0.051-0.113 | Min5 | |||||||||
| 0.114-0.499 | Min6 | |||||||||
| 0.500-1.000 | Min10 | |||||||||
| 1100-H16/1100-H26 | 0.006-0.019 | 19.0-24.0 | Min17.0 | Min1 | ||||||
| 0.020-0.031 | Min2 | |||||||||
| 0.032-0.050 | Min3 | |||||||||
| 0.051-0.162 | Min4 | |||||||||
| 1100-H18/1100-H28 | 0.006-0.019 | Min22.0 | - | Min1 | ||||||
| 0.020-0.031 | Min2 | |||||||||
| 0.032-0.050 | Min3 | |||||||||
| 0.051-0.128 | Min4 | |||||||||
| 1100-H112 | 0.025-0.499 | Min13.0 | Min7.0 | Min9 | ||||||
| 0.500-2.000 | Min12.0 | Min5.0 | Min14 | |||||||
| 2.001-3.000 | Min11.5 | Min4.0 | Min20 |
