1050 Aluminum sheet
1050 Aluminium alloy is a popular grade of aluminium ,belongs to commercially pure wrought family with a purity of 99.5% Aluminium for general sheet metal work where moderate strength is required.
Contact Us
WhatsAPP
QR code
Detail
1050 Aluminium alloy is a popular grade of aluminium ,belongs to commercially pure wrought family with a purity of 99.5% Aluminium for general sheet metal work where moderate strength is required.offers the best correction resistance compared to any alloy group
| Elements | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al |
| Content | 0.25 | 0.40 | 0.05 | 0.05 | 0.05 | - | 0.07 | 0.05 | 0.15 | Remain |
| Alloy Temper | Specified | Tensile strength | Yield strength | Elongation | ||||||
| Thickness(mm) | (MPa) | (MPa) | (%) | |||||||
| 1050-O/ 1050-H111 | 0.2-0.5 | 65-95 | Min20 | Min20 | ||||||
| 0.5-1.5 | Min22 | |||||||||
| 1.5-3.0 | Min26 | |||||||||
| 3.0-6.0 | Min29 | |||||||||
| 6.0-12.5 | Min35 | |||||||||
| 12.5-80.0 | ||||||||||
| 1050-H112 | 6.0-12.5 | Min75 | Min30 | Min20 | ||||||
| 12.5-80.0 | Min70 | Min25 | ||||||||
| 1050-H12 | 0.2-0.5 | 85-125 | Min65 | Min2 | ||||||
| 0.5-1.5 | Min4 | |||||||||
| 1.5-3.0 | Min5 | |||||||||
| 3.0-6.0 | Min7 | |||||||||
| 6.0-12.5 | Min9 | |||||||||
| 12.5-40.0 | ||||||||||
| 1050-H14 | 0.2-1.5 | 105-145 | Min85 | Min2 | ||||||
| 1.5-3.0 | Min4 | |||||||||
| 3.0-6.0 | Min5 | |||||||||
| 6.0-12.5 | Min6 | |||||||||
| 12.5-25 | ||||||||||
| 1050-H16 | 0.2-0.5 | 120-160 | Min100 | Min1 | ||||||
| 0.5-1.5 | Min2 | |||||||||
| 1.5-4.0 | Min3 | |||||||||
| 1050-H18 | 0.2-0.5 | Min135 | Min120 | Min1 | ||||||
| 0.5-1.5 | Min140 | Min2 | ||||||||
| 1.5-3.0 | Min2 | |||||||||
| 1050-H19 | 0.2-0.5 | Min155 | Min140 | Min1 | ||||||
| 0.5-1.5 | Min150 | Min130 | ||||||||
| 1.5-3.0 | ||||||||||
| 1050-H22 | 0.2-0.5 | 85-125 | Min55 | Min4 | ||||||
| 0.5-1.5 | Min5 | |||||||||
| 1.5-3.0 | Min6 | |||||||||
| 3.0-6.0 | Min11 | |||||||||
| 6.0-12.5 | Min12 | |||||||||
| 1050-H24 | 0.2-0.5 | 105-145 | Min75 | Min3 | ||||||
| 0.5-1.5 | Min4 | |||||||||
| 1.5-3.0 | Min5 | |||||||||
| 3.0-6.0 | Min8 | |||||||||
| 6.0-12.5 | ||||||||||
| 1050-H26 | 0.2-0.5 | 120-160 | Min90 | Min2 | ||||||
| 0.5-1.5 | Min3 | |||||||||
| 1.5-4.0 | Min4 | |||||||||
| 1050-H28 | 0.2-0.5 | Min140 | Min110 | Min2 | ||||||
| 0.5-1.5 | ||||||||||
| 1.5-3.0 | Min3 |
